2 MistCannon Rangers ready for despatch
The generator enables rapid deployment where no power supply is readily available
Vertical tilt from -20° to +45°
27 nozzles producing a fine mist spray
Turbofan propulsion of mist
Throw range of around 30m in still conditions
Ultra water-efficient at ~21 litres/minute
New, slim-design fan cowl
Originally developed in Scandinavia, and with
MistCannons project a giant plume of finely-atomised water droplets into the air to suppress dust effectively before it disperses into the environment. These robust machines cope easily with the harshest of conditions!
The MistCannon Ranger can propel mist up to 30m and can swivel by 270°, giving a maximum ground coverage of up to 2,800m² with a single sweep. A larger size cannon is also available for purchase only, which has a throw of up to 40m, covering up to 5,000m².
The Ranger is a fully self-contained dust suppression solution. It consists of a trailer-mounted bowser unit, with a new slim-design, ultra-efficient MistCannon mounted on the front and a generator set mounted on detachable brackets on the rear. The MistCannon Ranger's highway-tow chassis facilitates safe and easy relocation on site, although we do not recommend towing on the public highway. The 2000-litre bowser allows the unit to be used independently of a fixed water supply, with a continuous spraying time of around 90 minutes (dropping to 75 minutes for the larger cannon).
With Health & Safety Regulations tightening up, we can now offer a remote-control option, meaning that the MistCannon can be controlled from a safe distance – such as from inside a vehicle cab, office or control room.
Since Corgin introduced MistCannons to the UK market in 2012, their popularity has mushroomed as more and more clients prove their worth. As well as selling them for use all over the UK, we have exported MistCannons to places as diverse as Ireland, Denmark and even Mozambique! MistCannons can handle all manner of dust types, from coarse wood chip to ultra-fine incinerator ash. In addition to dust suppression, MistCannons can also be used for large-scale spraying and misting of disinfectants for surface sanitising.
Corgin
Features |
Benefits |
---|---|
Throw of up to 40m and electrical oscillation of up to 270° | Massive coverage of up to 5,000m² from one location |
Powerful turbofan and booster pump | For creating and propelling the fine mist plume |
Ultra-efficient water output | Saves water; longer spray time without bowser refill |
Stainless steel nozzles | For durability |
Hand-held remote control | Safe operation from a distance |
Water bowser | For rapid deployment and profitability on sites where no water supply is readily available |
Diesel generator set | Enabling rapid deployment where no power supply is readily available |
Water filtration system |
To help protect the pump & reduce incidence of nozzle blocking |
A good internet connection is required to open 3D models
Model (throw/bowser size) |
Ranger 30/2000 |
Ranger 40/2000 |
Availability |
Hire or Purchase |
Hire or Purchase |
Fan |
3 kW |
5.5 kW |
Pump |
2.2 kW |
2.2 kW |
Total kW |
6 kW |
8 kW |
Generator |
12.5 kVA |
12.5 kVA |
Nozzles |
27 |
33 |
Flow |
21 l/m |
26 l/m |
Working pressure |
10 bar |
10 bar |
Power connection (400V, 50Hz) |
16 A |
32 A |
Bowser size |
2000 litres |
2000 litres |
Weight (unladen, incl. generator) |
990 kg |
1,030 kg |
Vertical tilt |
-20 to +20° |
-20 to +20° |
Oscillation |
45-315° |
45-315° |
Maximum throw |
30 m |
40 m |
Length |
4.45 m |
4.45 m |
Width |
1.85 m |
1.85 m |
Height |
2.1 m |
2.1 m |
Optional Extras |
||
Remote control; automatic electric oscillation |
Model (throw/ |
Ranger 30/2000 |
Availability |
Hire or Purchase |
Fan |
3 kW |
Pump |
2.2 kW |
Total kW |
6 kW |
Generator |
12.5 kVA |
Nozzles |
27 |
Flow |
21 l/m |
Working pressure |
10 bar |
Power connection (400V, 50Hz) |
16 A |
Bowser Size |
2000 litres |
Weight (unladen, incl. generator) |
990 kg |
Vertical tilt |
-20 to +45° |
Oscillation |
45-315° |
Maximum throw |
30 m |
Length |
4.45 m |
Width |
1.85 m |
Height |
2.1 m |
Model (throw/ |
Ranger 40/2000 |
Availability |
Purchase |
Fan |
5.5 kW |
Pump |
2.2 kW |
Total kW |
8 kW |
Generator |
12.5 kVA |
Nozzles |
33 |
Flow |
26 l/m |
Working pressure |
10 bar |
Power connection (400V, 50Hz) |
32 A |
Bowser size |
2000 litres |
Weight (unladen) |
1,030 kg |
Vertical height |
-20 to +45° |
Oscillation |
45-315° |
Maximum throw |
40 m |
Length |
4.45 m |
Width |
1.85 m |
Height |
2.1 m |
Optional Extras |
|
Remote control; automatic electric oscillation |
Where are MistCannons used? |
Why are they selected? |
Quarries |
Remote control operation |
Mines |
Lower noise emissions |
Ports |
Low water usage |
Steelworks |
Rapid deployment from hire fleet |
Waste Handling Facilities |
Ease of mobility |
Demolition Sites |
Cooling and evaporation |
Construction Sites |
|
Bulk Materials Handling |
|
Aggregate Handling |
